LEDSON Phantom Work / Reverse Light – Combo Beam

LEDSON Phantom Work / Reverse Light – Combo Beam

* Retired product (as new)

LEDSON Phantom is one of LEDSON’s most recommended work and reverse lights thanks to its unique combined beam pattern, delivering both wide and long light distribution in a single unit.

The combo beam design is commonly found in LED light bars but is rare in reverse lights. Phantom combines 60° flood beam for wide-area illumination with 20° spot beam for extended reach, providing excellent visibility in all directions. The light is E-approved according to R10 (EMC), ensuring interference-free operation.

Key features

• Powerful combined beam pattern (4 spot + 4 flood reflectors)
• E-approved R10 (EMC protected)
• Combo beam: 60° flood + 20° spot
• 3600 lumens
• Cool white light (6000K)
• Suitable as both reverse light and work light
• DT cable included

Technical specifications

• Size: 7"
• Light source: 8 × 5 W CREE LEDs (total 40 W)
• Adjustable mounting bracket
• IP68 – waterproof and dustproof
• Operating voltage: 9–32 V

Dimensions & weight

• Width: 166 mm
• Height: 37 mm (excluding bracket) / 44 mm (including bracket)
• Depth: 58 mm
• Weight: 460 g

Wiring

• Red: Positive (+)
• Black: Negative (–)
